MB ASUS B650 AMD S-AM5 7A GEN/4X DDR5 5000/DP/HDMI/M.2/4X USB 3.2/USB-C/WIFI 6/BLUETOOTH/ATX/GAMA MEDIA/GAMER/RGB

CPUAMD SOCKET AM5 FOR AMD RYZEN™ 7000 SERIES DESKTOP PROCESSORS** REFER TO WWW.ASUS.COM FOR CPU SUPPORT LIST.CHIPSETAMD B650MEMORY4 X DIMM, MAX. 128GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800 ECC AND NON-ECC, UN-BUFFERED MEMORY*DUAL CHANNEL MEMORY ARCHITECTURESUPPORTS AMD EXTENDED PROFILES FOR OVERCLOCKING (EXPO™)OPTIMEM II* SUPPORTED MEMORY TYPES, DATA RATE(SPEED), AND NUMBER OF DRAM MODULE VARY DEPENDING ON THE CPU AND MEMORY CONFIGURATION, FOR MORE INFORMATION REFER TO WWW.ASUS.COM FOR MEMORY SUPPORT LIST.GRAPHICS1 X DISPLAYPORT*1 X HDMI® PORT*** SUPPORTS MAX. 8K@60HZ AS SPECIFIED IN DISPLAYPORT 1.4. **SUPPORTS 4K@60HZ AS SPECIFIED IN HDMI 2.1.EXPANSION SLOTSAMD RYZEN™ 7000 SERIES DESKTOP PROCESSORS1 X PCIE 4.0 X16 SLOTAMD B650 CHIPSET1 X PCIE 4.0 X16 SLOT (SUPPORTS X4 MODE)*2 X PCIE 4.0/3.0 X1 SLOTS* PCIE 4.0 X16 SLOT (SUPPORTS X4 MODE) FROM AMD B650 CHIPSET SHARES BANDWIDTH WITH M.2_3.STORAGETOTAL SUPPORTS 3 X M.2 SLOTS AND 4 X SATA 6GB/S PORTS*AMD RYZEN™ 7000 SERIES DESKTOP PROCESSORSM.2_1 SLOT (KEY M), TYPE 2242/2260/2280(SUPPORTS PCIE 5.0 X4 MODE)M.2_2 SLOT (KEY M), TYPE 2242/2260/2280 (SUPPORTS PCIE 4.0 X4 MODE)AMD B650 CHIPSETM.2_3 SLOT (KEY M), TYPE 2242/2260/2280/22110 (SUPPORTS PCIE 4.0 X4 MODE)**4 X SATA 6GB/S PORT*AMD RAID XPERT TECHNOLOGY SUPPORTS BOTH NVME RAID 0/1/10 AND SATA RAID 0/1/10.** M.2_3 SLOT SHARES BANDWIDTH WITH PCIE 4.0 X16 SLOT (SUPPORTS X4 MODE) WHEN M.2_3 SLOT IS OPERATING IN PCIE MODE, M.2_3 WILL BE DISABLED.ETHERNET1 X INTEL® 2.5GB ETHERNETASUS LANGUARDWIRELESS & BLUETOOTHWI-FI 6E2X2 WI-FI 6E (802.11 A/B/G/N/AC/AX)SUPPORTS 2.4/5GHZ FREQUENCY BANDBLUETOOTH V5.2* WI-FI 6E 6GHZ REGULATORY MAY VARY BETWEEN COUNTRIES, AND FUNCTION WILL BEREADY IN WINDOWS 11 OR LATER.USBREAR USB (TOTAL 9 PORTS)1 X USB 3.2 GEN 2X2 PORT (1 X USB TYPE-C®)4 X USB 3.2 GEN 2 PORTS (3 X TYPE-A + 1 X USB TYPE-C®)4 X USB 2.0 PORTS (4 X TYPE-A)FRONT USB (TOTAL 7 PORTS)1 X USB 3.2 GEN 2 CONNECTOR (SUPPORTS USB TYPE-C®)1 X USB 3.2 GEN 1 HEADER SUPPORTS ADDITIONAL 2 USB 3.2 GEN 1 PORTS2 X USB 2.0 HEADERS SUPPORTS ADDITIONAL 4 USB 2.0 PORTSAUDIOROG SUPREMEFX 7.1 SURROUND SOUND HIGH DEFINITION AUDIO CODEC ALC4080 - IMPEDANCE SENSE FOR FRONT AND REAR HEADPHONE OUTPUTS - SUPPORTS: JACK-DETECTION, MULTI-STREAMING, FRONT PANEL JACK-RETASKING - HIGH QUALITY 120 DB SNR STEREO PLAYBACK OUTPUT AND 113 DB SNR RECORDING INPUT - SUPPORTS UP TO 32-BIT/384 KHZ PLAYBACKAUDIO FEATURES - SUPREMEFX SHIELDING TECHNOLOGY - SAVITECH SV3H712 AMP- REAR OPTICAL S/PDIF OUT PORT- PREMIUM AUDIO CAPACITORS- AUDIO COVERBACK PANEL I/O PORTS1 X USB 3.2 GEN 2X2 PORT (1 X USB TYPE-C®)4 X USB 3.2 GEN 2 PORTS (3 X TYPE-A + 1 X USB TYPE-C®)4 X USB 2.0 PORTS (4 X TYPE-A)1 X DISPLAYPORT1 X HDMI® PORT1 X WI-FI MODULE1 X INTEL® 2.5GB ETHERNET PORT5 X AUDIO JACKS 1 X BIOS FLASHBACK™ BUTTONINTERNAL I/O CONNECTORSFAN AND COOLING RELATED 1 X 4-PIN CPU FAN HEADER1 X 4-PIN CPU OPT FAN HEADER1 X 4-PIN AIO PUMP HEADER4 X 4-PIN CHASSIS FAN HEADERSPOWER RELATED 1 X 24-PIN MAIN POWER CONNECTOR1 X 8-PIN +12V POWER CONNECTOR1 X 4-PIN +12V POWER CONNECTORSTORAGE RELATED 3 X M.2 SLOTS (KEY M) 4 X SATA 6GB/S PORTSUSB 1 X USB 3.2 GEN 2 CONNECTOR (SUPPORTS USB TYPE-C®)1 X USB 3.2 GEN 1 HEADER SUPPORTS ADDITIONAL 2 USB 3.2 GEN 1 PORTS2 X USB 2.0 HEADERS SUPPORTS ADDITIONAL 4 USB 2.0 PORTSMISCELLANEOUS3 X ADDRESSABLE GEN 2 HEADERS1 X AURA RGB HEADER1 X CLEAR CMOS HEADER1 X CPU OVER VOLTAGE JUMPER1 X FRONT PANEL AUDIO HEADER (AAFP)1 X S/PDIF OUT HEADER1 X 20-3 PIN SYSTEM PANEL HEADER WITH CHASSIS INTRUDE FUNCTION1 X THERMAL SENSOR HEADER1 X THUNDERBOLT™HEADER1 X COM_DEBUGHEADERSPECIAL FEATURESEXTREME ENGINE DIGI+- 5K BLACK METALLIC CAPACITORS ASUS Q-DESIGN - M.2 Q-LATCH- PCIE SLOT Q-RELEASE- Q-LED- Q-DIMM- Q-SLOTASUS THERMAL SOLUTION- M.2 HEATSINK- VRM HEATSINK DESIGNASUS EZ DIY- BIOS FLASHBACK™ BUTTON- BIOS FLASHBACK™ LED- PROCOOL- PRE-MOUNTED I/O SHIELD- SAFESLOT- SAFEDIMMAURA SYNC- AURA RGB HEADER- ADDRESSABLE GEN 2 HEADERSSOFTWARE FEATURESROG EXCLUSIVE SOFTWARE- GAMEFIRST VI- ROG CPU-Z- SONIC STUDIO III + SONIC STUDIO VIRTUAL MIXER + SONIC SUITE COMPANION- SONIC RADAR III- DTS® SOUND UNBOUND - ANTI-VIRUS SOFTWAREASUS EXCLUSIVE SOFTWAREARMOURY CRATE- AIDA64 EXTREME (60 DAYS FREE TRIAL) - AURA CREATOR- AURA SYNC- FAN XPERT 4- POWER SAVING- TWO-WAY AI NOISE CANCELLATIONAI SUITE 3- TPU- DIGI+ VRM- TURBO APP- PC CLEANERMYASUSWINRARUEFI BIOSASUS EZ DIY - ASUS CRASHFREE BIOS 3 - ASUS EZ FLASH 3 - ASUS UEFI BIOS EZ MODEFLEXKEYBIOS256 MB FLASH ROM, UEFI AMI BIOSMANAGEABILITYWOL BY PME, PXEACCESSORIESCABLES2 X SATA 6GB/S CABLES ADDITIONAL COOLING KIT1 X THERMAL PAD FOR M.2MISCELLANEOUS1 X ASUS WI-FI MOVING ANTENNAS 1 X CABLE TIES PACK1 X M.2 Q-LATCH PACKAGE1 X ROG KEY CHAIN1 X ROG STRIX STICKERS1 X ROG STRIX THANK YOU CARD2 X M.2 RUBBER PACKAGESDOCUMENTATION1 X USER GUIDEOPERATING SYSTEMWINDOWS® 11 64-BITFORM FACTORATX FORM FACTOR12 INCH X 9.6 INCH ( 30.5 CM X 24.4 CM )
