MB ASUS A520 AMD S-AM4 5A GEN/4X DDR4 2800/2X DP/HDMI/D-SUB/M.2/4X USB3.2/MICRO ATX/GAMA BASICA

TARJETA MADRE PARA JUEGOS AMD A520 (RYZEN AM4) MICRO ATX CON SOPORTE M.2, WI-FI 802.11AC, DISPLAYPORT, HDMI, D-SUB, PUERTOS USB 3.2 GEN 1, SATA 6 GBPS Y PUERTOS AURA GEN 2 DIRECCIONABLESSOCKET AMD AM4: LISTO PARA PROCESADORES DE ESCRITORIO RYZEN 5000 SERIES / 4000 G-SERIES / 3000 SERIES.REFRIGERACION COMPLETA: GRAN DISIPADOR DE CALOR VRM, DISIPADOR DE CALOR PCH, FAN XPERT 2.CONECTIVIDAD ULTRARRAPIDA: DUAL M.2, PCIE 4.0, ETHERNET DE 1 GB, USB 3.2 GEN 2 TIPO-A.HECHA PARA JUEGOS EN LINEA: TECNOLOGIA WI-FI 802.11AC, TUF LANGUARD Y TURBOLAN.AURA SYNC RGB: PUERTOS RGB INTEGRADOS Y PUERTOS GEN 2 DIRECCIONABLES PARA TIRAS DE LED RGB, QUE SE SINCRONIZAN FACILMENTE CON HARDWARE COMPATIBLE CON AURA SYNC.

Especificaciones Técnicas

MODELTUF GAMING A520M-PLUS WIFICPUAMD RYZEN 5000 SERIES/ 5000 G-SERIES/ 4000 G-SERIES/ 3000 SERIES DESKTOP PROCESSORSREFER TO WWW.ASUS.COM FOR CPU SUPPORT LISTREFER TO WWW.ASUS.COM FOR CPU SUPPORT LIST.CHIPSETA520MEMORIACANALES DE MEMORIA:4 X DIMM, MAX. 128GB, DDR44 X DIMM, MAX. 128GB, DDR4 4866(OC)/4800(OC)/4600(OC)/4466(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200/3000/2800/2666/2400/2133 MHZ, UN-BUFFERED MEMORYDUAL CHANNEL MEMORY ARCHITECTUREECC MEMORY (ECC MODE) SUPPORT VARIES BY CPU.REFER TO WWW.ASUS.COM FOR THE MEMORY QVL (QUALIFIED VENDORS LISTS), AND MEMORY FREQUENCY SUPPORT DEPENDS ON THE CPU TYPES.GRAFICOS1 X DISPLAYPORT 1.21 X D-SUB1 X HDMI PORT***1 X DISPLAYPORT 1.21 X HDMITM 2.1(4K60HZ)1 X D-SUBGRAPHICS SPECIFICATIONS MAY VARY BETWEEN CPU TYPES.RANURAS DE EXPANSIONAMD RYZEN 5000 SERIES/ 5000 G-SERIES/ 4000 G-SERIES/ 3000 SERIES DESKTOP PROCESSORS1 X PCIE 3.0 X16 SLOT (SUPPORTS X16 MODE)AMD A520 CHIPSET2 X PCIE 3.0 X1 SLOTSALMACENAMIENTOAMD RYZEN 5000 SERIES/ 4000 G-SERIES/ 3000 SERIES DESKTOP PROCESSORSM.2 SLOT (KEY M), TYPE 2242/2260/2280 (SUPPORTS PCIE 3.0 X4 SATA MODES)AMD A520 CHIPSET4 X SATA 6GB/S PORTSSUPPORT RAID 0, 1, 10 ETHERNETTUF LANGUARD1 X REALTEK 1GB ETHERNETTUF LANGUARDWIRELESS & BLUETOOTHREALTEK WI-FI 5 8821CE1X1 WI-FI 5 (802.11 A/B/G/N/AC) WITH MU-MIMOSUPPORTS DUAL FREQUENCY BAND 2.4/5GHZSUPPORTS CHANNEL BANDWIDTH: HT20/HT40/HT80BLUETOOTH V5.0USBUSB TRASERO:TOTAL 6 PORTS4 X USB 3.2 GEN 1 PORTS (4 X TYPE-A)2 X USB 2.0 PORTS (2 X TYPE-A)USB FRONTAL:TOTAL 6 PORTS1 X USB 3.2 GEN 1 HEADER SUPPORTS ADDITIONAL 2 USB 3.2 GEN 1 PORTS2 X USB 2.0 HEADERS SUPPORT ADDITIONAL 3 USB 2.0 PORTSAUDIOREALTEK ALC887/897 7.1 SURROUND SOUND HIGH DEFINITION AUDIO CODECSUPPORTS : JACK DETECTION, MULTI-STREAMING, FRONT PANEL JACK-RETASKINGSUPPORTS UP TO 24-BIT/192 KHZ PLAYBACKAUDIO FEATURES- AUDIO SHIELDING- PREMIUM JAPANESE AUDIO CAPACITORS- DEDICATED AUDIO PCB LAYERSA CHASSIS WITH AN HD AUDIO MODULE IN THE FRONT PANEL IS REQUIRED TO SUPPORT 7.1 SURROUND SOUND AUDIO OUTPUT.PUERTOS E/S TRASEROS4 X USB 3.2 GEN 1 PORTS (4 X TYPE-A)2 X USB 2.0 PORTS (2 X TYPE-A)1 X DISPLAYPORT1 X HDMI PORT1 X D-SUB1 X ASUS WI-FI MODULE1 X REALTEK 1GB ETHERNET PORT3 X AUDIO JACKS1 X BIOS FLASHBACK™ BUTTON1 X PS/2 KEYBOARD/MOUSE COMBO PORTPUERTOS INTERNOSFAN AND COOLING RELATED1 X 4-PIN CPU FAN HEADER2 X 4-PIN CHASSIS FAN HEADERSPOWER RELATED1 X 24-PIN MAIN POWER CONNECTOR1 X 8-PIN +12V POWER CONNECTORSTORAGE RELATED1 X M.2 SLOT (KEY M)4 X SATA 6GB/S PORTSUSB1 X USB 3.2 GEN 1 HEADER SUPPORTS ADDITIONAL 2 USB 3.2 GEN 1 PORTS2 X USB 2.0 HEADERS SUPPORT ADDITIONAL 3 USB 2.0 PORTSMISCELLANEOUS2 X AURA ADDRESSABLE GEN 2 HEADERNEOUS2 X AURA RGB HEADERS1 X CLEAR CMOS HEADER1 X COM PORT HEADER1 X FRONT PANEL AUDIO HEADER (AAFP)1 X S/PDIF OUT HEADER1 X SPEAKER HEADER1 X SPI TPM HEADER (14-1PIN)1 X 10-1 PIN SYSTEM PANEL HEADERFUNCIONES ESPECIALES DE ASUSASUS TUF PROTECTION- DIGI+ VRM- ESD GUARDS- TUF LANGUARD- OVERVOLTAGE PROTECTION- SAFESLOT CORE+- STAINLESS-STEEL BACK I/OASUS Q-DESIGN- Q-DIMM- Q-SLOTASUS THERMAL SOLUTION- VRM HEATSINK DESIGNASUS EZ DIY- BIOS FLASHBACK™ BUTTON- BIOS FLASHBACK™ LEDAURA SYNC- AURA RGB HEADERS- ADDRESSABLE GEN 2 RGB HEADERSSOFTWAREASUS EXCLUSIVE SOFTWAREARMOURY CRATE- AURA CREATOR- AURA SYNCAI SUITE 3- PERFORMANCE AND POWER SAVING UTILITYTURBOV EVOEPUDIGI+ VRMFAN XPERT 2+- EZ UPDATE- PC CLEANER- SYSTEM INFORMATIONTUF GAMING CPU-ZAI CHARGERASUS TURBO LANDAEMON TOOLSMYASUSNORTON ANTI-VIRUS SOFTWARE (FREE TRIAL VERSION)WINRARUEFI BIOSASUS EZ DIY- ASUS CRASHFREE BIOS 3- ASUS EZ FLASH 3- ASUS UEFI BIOS EZ MODEBIOS128 MB FLASH ROM, UEFI AMI BIOSMANEJABILIDADWOL BY PME, PXEACCESORIOSCABLES2 X SATA 6GB/S CABLESMISCELLANEOUS1 X I/O SHIELD1 X M.2 SSD SCREW PACKAGE1 X ASUS WI-FI MOVING ANTENNA1 X TUF GAMING STICKERINSTALLATION MEDIA1 X SUPPORT DVDDOCUMENTATION1 X TUF CERTIFICATION CARD1 X USER MANUALSISTEMA OPERATIVOWINDOWS 10 64-BITWINDOWS 7 64-BIT *1WINDOWS 10 64-BITFACTOR DE FORMAMATX9.6 INCH X 9.6 INCH ( 24.4 CM X 24.4 CM )
