MB ASUS B760 INTEL S-1700 14A GEN /2X DDR4 3200 /HDMI /VGA /2X M.2 /4X USB 3.2 /MICRO ATX /GAMA MEDIA

MODELPRIME B760M-K D4CPUINTEL SOCKET LGA1700 FOR 13TH GEN INTEL CORE PROCESSORS 12TH GEN INTEL CORE, PENTIUM® GOLD AND CELERON PROCESSORSSUPPORTS INTEL TURBO BOOST TECHNOLOGY 2.0 AND INTEL TURBO BOOST MAX TECHNOLOGY 3.0REFER TO WWW.ASUS.COM FOR CPU SUPPORT LIST.INTEL TURBO BOOST MAX TECHNOLOGY 3.0 SUPPORT DEPENDS ON THE CPU TYPES.CHIPSETINTEL B760 CHIPSETMEMORY2 X DIMM, MAX. 64GB, DDR45333(OC)/5066(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 NON-ECC, UN-BUFFERED MEMORY*DUAL CHANNEL MEMORY ARCHITECTURESUPPORTS INTEL EXTREME MEMORY PROFILE (XMP)SUPPORTED MEMORY TYPES, DATA RATE (SPEED), AND NUMBER OF DRAM MODULES VARY DEPENDING ON THE CPU AND MEMORY CONFIGURATION, FOR MORE INFORMATION PLEASE REFER TO CPU/MEMORY SUPPORT LIST UNDER THE SUPPORT TAB OF PRODUCT INFORMATION SITE OR VISITGRAPHICS1 X VGA PORT1 X HDMI PORTGRAPHICS SPECIFICATIONS MAY VARY BETWEEN CPU TYPES. PLEASE REFER TO WWW.INTEL.COM FOR ANY UPDATES.SUPPORTS 4K 60HZ AS SPECIFIED IN HDMI 2.1.EXPANSION SLOTSINTEL 13TH & 12TH GEN PROCESSORS1 X PCIE 4.0 X16 SLOTINTEL B760 CHIPSET2 X PCIE 4.0 X1 SLOTSNOTE: TO ENSURE COMPATIBILITY OF THE DEVICE INSTALLED, PLEASE REFER TO HTTPS://WWW.ASUS.COM/SUPPORT/ FOR THE LIST OF SUPPORTED PERIPHERALS.STORAGETOTAL SUPPORTS 2 X M.2 SLOTS AND 4 X SATA 6GB/S PORTSINTEL 13TH 12TH GEN PROCESSORSM.2_1 SLOT (KEY M), TYPE 2242/2260/2280 (SUPPORTS PCIE 4.0 X4 MODE)INTEL B760 CHIPSETM.2_2 SLOT (KEY M), TYPE 2242/2260/2280 (SUPPORTS PCIE 4.0 X4 MODE)4 X SATA 6GB/S PORTSINTEL RAPID STORAGE TECHNOLOGY SUPPORTS SATA RAID 0/1/5/10.ETHERNET1 X REALTEK 2.5GB ETHERNETUSBREAR USB (TOTAL 6 PORTS)4 X USB 3.2 GEN 1 PORTS (4 X TYPE-A)2 X USB 2.0 PORTS (2 X TYPE-A）FRONT USB (TOTAL 5 PORTS)1 X USB 3.2 GEN 1 HEADER SUPPORTS 2 ADDITIONAL USB 3.2 GEN 1 PORTS2 X USB 2.0 HEADERS SUPPORT 3 ADDITIONAL USB 2.0 PORTSAUDIOREALTEK 7.1 SURROUND SOUND HIGH DEFINITION AUDIO CODEC- SUPPORTS: JACK-DETECTION, MULTI-STREAMING, FRONT PANEL JACK-RETASKING- SUPPORTS UP TO 24-BIT/192 KHZ PLAYBACKAUDIO FEATURES- AUDIO SHIELDING- PREMIUM AUDIO CAPACITORS- DEDICATED AUDIO PCB LAYERSA CHASSIS WITH AN HD AUDIO MODULE IN THE FRONT PANEL IS REQUIRED TO SUPPORT 7.1 SURROUND SOUND AUDIO OUTPUT.BACK PANEL I/O PORTS4 X USB 3.2 GEN 1 PORTS (4 X TYPE-A)2 X USB 2.0 PORTS (2 X TYPE-A)1 X VGA PORT1 X HDMI PORT1 X REALTEK 2.5GB ETHERNET PORT3 X AUDIO JACKS1 X PS/2 KEYBOARD/MOUSE COMBO PORTINTERNAL I/O CONNECTORSFAN AND COOLING RELATED1 X 4-PIN CPU FAN HEADER1 X 4-PIN CHASSIS FAN HEADERPOWER RELATED1 X 24-PIN MAIN POWER CONNECTOR1 X 8-PIN +12V POWER CONNECTORSTORAGE RELATED2 X M.2 SLOTS (KEY M)4 X SATA 6GB/S PORTSUSB1 X USB 3.2 GEN 1 HEADER SUPPORTS 2 ADDITIONAL USB 3.2 GEN 1 PORTS2 X USB 2.0 HEADERS SUPPORT 3 ADDITIONAL USB 2.0 PORTSMISCELLANEOUS2 X ADDRESSABLE GEN 2 HEADERS1 X AURA RGB HEADER1 X CLEAR CMOS HEADER1 X COM PORT HEADER1 X FRONT PANEL AUDIO HEADER (AAFP)1 X S/PDIF OUT HEADER1 X SPEAKER HEADER1 X SPI TPM HEADER (14-1PIN)1 X 10-1 PIN SYSTEM PANEL HEADERSPECIAL FEATURESASUS 5X PROTECTION III- DIGI+ VRM- LANGUARD- OVERVOLTAGE PROTECTION- SAFESLOT CORE- STAINLESS-STEEL BACK I/OASUS Q-DESIGN- Q-DIMM- Q-LED CORE- Q-SLOTASUS EZ DIY- PROCOOLASUS THERMAL SOLUTION- VRM HEATSINK DESIGNAURA SYNC- AURA RGB HEADER- ADDRESSABLE GEN 2 HEADERSSOFTWARE FEATURESASUS EXCLUSIVE SOFTWAREARMOURY CRATE- AURA SYNC- FAN XPERT- POWER SAVINGAI SUITE 3- DIGI+ VRM- PC CLEANERASUS CPU-ZNORTON 360 DELUXE (60 DAYS FREE TRIAL)WINRARUEFI BIOSASUS EZ DIY- ASUS CRASHFREE BIOS 3- ASUS EZ FLASH 3- ASUS UEFI BIOS EZ MODEBIOS128 MB FLASH ROM, UEFI AMI BIOSMANAGEABILITYWOL BY PME, PXEACCESSORIESCABLES2 X SATA 6GB/S CABLESMISCELLANEOUS1 X I/O SHIELD2 X M.2 ANCHORSDOCUMENTATION1 X USER GUIDEOPERATING SYSTEMWINDOWS 11, WINDOWS 10 64-BITFORM FACTORMATX FORM FACTOR9.6 INCH X 8.3 INCH (24.4CM X 21.1CM)
